Conveying and Hoisting Solutions has an extensive range of materials handling equipment available for hire.

Moving bulk material over distance? The industrial steel trough conveyor from Conveying & Hoisting Solutions carries sand, soil, gravel or demolition spoil quickly with solid side walls that prevent spill. Hire units are built with rugged rollers for demanding site conditions.

With one of the largest range of Conveyor Belts for hire in Australia, choose from our Industrial Steel Flatbed Conveyor, Industrial Steel Trough Conveyor, Lightweight Aluminium Flatbed Conveyor or Lightweight Aluminium Trough Conveyor.

Our Industrial Steel Trough Conveyor is designed for medium duty applications. Available in a 300mm or 600mm belt in 4 metre, 7 metre or 10 metre lengths, the Industrial Steel Trough Conveyor is suitable for earth moving, landscaping, construction, demolition, pool, mining, quarry and or any DIY projects.

If you are looking to hire or rent an Industrial Steel Trough Conveyor, please contact us today.

Call us today! (02) 9707 2797

Features

  • Designed for medium duty use
  • Ability to use larger hoppers
  • Available in 415V (600mm wide), as well as standard 240V (300mm wide)

Optional Extras

  • Conveyor stands
  • Hopper

Contact Us

Specifications

300mm Belt

Conveyor Type Length (m) Width (mm) Max Slope Mass (kg) Max Capacity Belt Speed (m/min) Volume Movable Capacity (with soil) Power
Medium Duty 4m 475** 22° 190kgs 150kgs 42 28m3/hr 30t/hr 240V(10amp)
Medium Duty 7m 475** 22° 260kgs 150kgs 42 28m3/hr 30t/hr 240V(10amp)
Medium Duty 10m 475** 22° 350kgs 150kgs 42 28m3/hr 30t/hr 240V(10amp)

** Deduct 100mm for actual belt width. ** Additional width for the control box housing should be allowed if being slid through an opening (approx 75mm).

600mm Belt

Conveyor Type Length (m) Width (mm) Max Slope Mass (kg) Max Capacity Belt Speed (m/min) Volume Movable Capacity (with soil) Power
Medium Duty 4m 750** 22° 220kgs 200kgs 42 100m3/hr 100t/hr 415v
Medium Duty 7m 750** 22° 360kgs 200kgs 42 100m3/hr 100t/hr 415v
Medium Duty 10m 750** 22° 520kgs 150kgs 42 100m3/hr 100t/hr 415v

** Deduct 100mm for actual belt width. ** Additional width for the control box housing should be allowed if being slid through an opening (approx 75mm).

Frequently Asked Questions

What belt width is available?

Standard belts are 350 millimetres wide with options up to 600 millimetres on request.

Does the conveyor include a hopper?

Hopper trays can be added for controlled feed of loose material.

How do I clean the belt?

Use water spray at low pressure after power isolation and allow belt to dry before next operation.
